Features:
Handing:
Handed; field reversible. The lockset can be re-handed without disassembling the lock case.
Door Thickness:
1-3/4' (4mm) standard. Optional door thickness available; consult factory.
Backset: 2-3/4' (70mm).
Lockcase:
Heavy gauge steel, with zinc dichromate finish for corrosion resistance. 5-7/8' (149mm) x 4' (102mm) x 15/16' (24mm).
Armored Front:
Heavy gauge steel, 8' (203 mm) x 1-1/4' (32mm) x 3/32' (2mm). Accommodates flat doors and doors beveled 1/8' (3mm) in 2' (51mm).
Faceplate:
Wrought brass or bronze, attached by machine screws to lockcase front.
Latchbolt:
Stainless steel, 2 piece mechanical with anti-friction insert. 5/8' (16mm) x 1' (25mm) x 3/4' (19mm) throw.
Auxiliary Latchbolt:
9/16' (14mm) effective throw and 3/8' (10mm) effective auxiliary latch deadlocking.
Deadbolt:
One-piece stainless steel, 19/32' (15mm) x 1 1/4' (32mm) x 1' (25mm) throw.
Hub:
Knob: nickel steel, 5/16' (8mm) and 9/32'.
Lever: nickel steel, 5/16' (8mm).
Spacing:
Center to center, hub to cylinder: 3-5/8' (92mm).
Center to center, hub to turnpiece: 2-7/16' (62 mm).
Strike:
Wrought brass or bronze, ANSI straight lip standard, 4-7/8' (124mm) x 1-1/4' (32mm) 1-1/8' (29mm) lip to center. Optional strikes, lip lengths and ANSI wrought strike box available.
Keys:
Two nickel silver standard.
Keying Features Available:
• Master keying
• Construction master keying
• Visual key control
• Concealed key control
• High security cylinder
• Interchangeable core (IC)-Choice Base, Plus, Flex and HS
